技术参数 Technical Date
★设备效率：900~1200PCS/H
★设备精度(mm)：±0.3mm
★伺服系统：三菱
★PLC控制：三菱
★人机界面：信捷
★丝杆/导轨：采用HIWIN精密滚珠丝杆和直线加宽导轨
★减速机：TWT
★气动元件：SMC(日本)或亚德客
★D：OMROM或基恩士
★设备外形尺寸：1850mm(L)*1300mm(W)*1700(H)mm
★设备总重量：约400KG Total
★设备总功率：约0.37KW Total
★气压（Mpa）：0.4～0.6Mpa
★工作电压:AC220V50~60HZ
★Equipment efficiency: 900 ~ 1200PCS / H
★Equipment Accuracy (mm): ± 0.3mm
★Servosystem: Mitsubishi
★PLC control system: Mitsubishi
★HMI: XINJE
★Screw / rail: The HIWIN precision ball screw & Straight line widening
★Reducer: TWT
★Pneumatic components: SMC (Japan) or Airtac
★D: OMRON or Keyence
★Equipment Dimensions: 1850mm (*) * 1300mm (W) * 1700 (H) mm
★Total weight: about 400KG
★Total power: about 0.37KW
★Air pressure (Mpa): 0.4 ~ 0.6Mpa
★Operating voltage: AC220V50 ~ 60HZ
功能介绍 Function Ineroduction
★全自动INLINE设计方式,无需人工操作
★ICT静态+动态测试(根据客户需求配备)
★自动区分良品/不佳品产品。
★自动读写条码功能(根据客户需求配备扫描枪或CCD)
★测试前PCBA方向检测
★测试速度比手工快30%以上，无人化作业，比手工操作减少1人
★ICT测试治具只需修改载板可直接安装使用
★Designed by full-automatic，Manual operation un-necessary
★ICT Static&Dynamic testing(According to customers requirements
★Distinguished PASS OR FAIL products automatically.
★Bar-code reading automatically.( According customer's requirements to provide scanner or CCD)
★PCBA direction confrimed before testing.
★Faster than manual testing about 30% or more, unmanned operation than manual operation reduced 1 operator at least.
★ICT test fixture can be installed directly just modify the carrier plate .
